Specifications
Scan Engine
Linear Imager CCD Solid-state
Light Source
Red LED 617 nm
Contrast Ratio
Minimum 15%
Resolution
0.077 mm / 3 mils (Linear Barcodes)
Depth of field
Code 39: 4 mils: 2.5 to 22.0 cm
Code 39: 5 mils: 2.0 to 30.0 cm
Code 39: 7.5 mils: 1.0 to 45.0 cm
Code 39: 10 mils: 1.0 to 60.0 cm
Code 39: 20 mils: 3.0 to 103.0 cm
EAN/UPCA: 13 mils: 1.0 to 68.0 cm
Performance may be impacted by Bar code quality and environmental conditions
Ambient Light Immunity
0 to120,000 Lux
Symbologies supported
1D:Auto-discriminates all standard 1D codes including GS1 DataBar™ linear codes
Programming Method
Automatic: Software commands through the RS-232 / USB interfaces
Datalogic Aladdin™: Windows configuration program
Driver available
JavaPOS, OPOS Utilities
Indicators/Controls
Beeper (Adjustable Tone)
Datalogic’s "Green Spot" Good read feedback
Good read LED
Supply Voltage
5 VDC +/- 5%
Power Consumption
Operating (Typical): 165 mA @ 5 VDC
Standby/Idle (Typical): 40 mA @ 5 VDC
Drop Specification
Designed to withstand repeated 1.5m drops to concrete
Environmental Sealing
IP42
ESD Protection
+/- 16 kV air discharge
Operating Environment
0° ~ 50°C
Storage Environment
-40° ~ 70°C
EMC/Safety Standards
The product meets necessary safety and regulatory approvals for its intended use.
Complete list in Quick Reference guide
Complies to EU RoHS & China RoHS
LED Classification: IEC 60825-1 Class 1 LED Product
External Dimensions (WxDxH)
Scanner: 67 x 107 x 1563 mm
